Description
| Item No. | SCL1-BD-A |
| Number of Poles | 3P (customizable) |
| Control Type | DC Electromagnetic Control |
| Rated Current (In) | 40A-65A |
| Rated Insulation Voltage (Ui) | 690V AC |
| Rated Operational Voltage (Ue) | AC 50/60Hz, 220V/380V/690V |
| Standard Coil Voltage | DC 24V (other DC voltages customizable) |
| Connection Type | Lug Terminal |
| Mechanical Durability | ≥10 million cycles |
| Rated Ultimate Breaking Capacity (Icu) at 380V AC | 6-8 times rated current |
| Utilization Category | AC-3 |
| Auxiliary Contact | NO/NC combination customizable |
| Compliance Standard | IEC 60947-4-1 |
| Customizable Options | DC coil voltage, number of poles, auxiliary contact, silk screen, packaging |
